Terraline Core

Fixed. Cabled. Always Ready.

The Terraline Core is a fixed auger alignment monitor designed for all machine sizes. The sensor mounts on your auger and is cabled back to the cabin for power — no batteries, no charging, just power-on and drill. Built for operators who want extreme reliability and consistency from a permanently installed system.

Key Features

Align while actively drilling — no need to stop (proprietary real-time system)

Sensors enclosed in flexible epoxy for maximum vibration resistance

Fixed auger alignment monitoring — always on, always ready

Designed for all machine sizes

Sensor cabled back to cabin for power — no charging ever required

Use your own phone or tablet as the display

Real-time alignment feedback while drilling

Rugged, weather-resistant sensor construction

Accuracy ±0.1° (±0.3° in rock)

Range 360°

Update Rate 10Hz

Power Fixed (Machine)

Machine Size All Sizes

Operating Temp -20°C to 60°C

Request a Quote

Why Terraline Core?

No Charging Required

The sensor is cabled back to your machine's cabin for power. Start your shift and get straight to work — zero downtime waiting for batteries.

Use Your Own Device

No proprietary display to buy or replace. Connect your own phone or tablet for a familiar, intuitive interface right in the cab.

Built for the Job Site

Designed for all machine sizes from compact rigs to large piling machines. Robust sensor design handles the vibration, dust, and demands of real production drilling.

Field Proven

Tested across tens of thousands of metres of drilling in real production conditions across multiple machine types and operating styles.

Drill & Align at the Same Time

Most systems on the market require you to stop drilling, align, then continue. Terraline's proprietary technology gives real-time alignment feedback while you're actively drilling — even in extremely hard rock. More metres, less downtime.

Flexible Epoxy Sensors

Every sensor is enclosed in flexible epoxy — not a rigid housing. This absorbs the intense vibration from hard-ground drilling that destroys conventional sensors, keeping the Core performing reliably where others fail.

Ideal Applications

Where a permanently fitted, always-on alignment system pays for itself.

Large-Scale Piling & Foundations

High-volume piling and foundation programmes where alignment on every pile needs to be right first time, shift after shift.

Ground Improvement

Ensure consistent column alignment across ground improvement projects with real-time angle feedback for every drill point.

Infrastructure Projects

Ideal for large-scale infrastructure drilling where a permanently installed, always-on alignment system is the practical choice.

How It Compares

Feature		This product
Machine Size	Up to 8T	All Sizes	All Sizes
Power	Battery	Fixed (Machine)	Fixed (Machine)
Installation	Portable	Permanent	Permanent
Display	Your Phone/Tablet	Your Phone/Tablet	Integrated System
Depth Measurement	—	—	✓ Standard
GPS Module	—	—	✓ Optional
